UpUpUppppppp- 客户端
1.Unity里编写客户端的代码 2.在Unity3d中创建脚本"SocketClient"
using System;
using System.Collections;
using System.Collections.Generic;
using System.Net;
using System.Net.Sockets;
using System.Text;
using System.Threading;
using UnityEngine;
public delegate void DelegateMsg(string Msg);
public class SocketClient
{
//客户端socket
private Socket clientSocket;
//服务器IP和端口
public string ServerIP;
public int ServerPort;
public DelegateMsg delegateMsg;
//收消息的线程
private Thread acceptMsgThread;
private int MAX_SEND_FILE_LENGTH = 4096;
//构造函数
public SocketClient(string _serverIP, int _serverPort)
{
ServerIP = _serverIP;
ServerPort = _serverPort;
}
/// <summary>
/// 连接服务器
/// </summary>
/// <returns></returns>
public bool ConnectServer()
{
if (ServerIP == null || ServerPort == 0)
{
return false;
}
try
{
//初始化socket对象
clientSocket = new Socket(AddressFamily.InterNetwork, SocketType.Stream, ProtocolType.Tcp);
//初始化地址和端口号
IPAddress serverIp = IPAddress.Parse(ServerIP);
IPEndPoint endPoint = new IPEndPoint(serverIp, ServerPort);
//连接服务器
clientSocket.Connect(endPoint);
//新建线程，接受服务端下发的消息
acceptMsgThread = new Thread(AcceptMsgs);
acceptMsgThread.IsBackground = true;
acceptMsgThread.Start();
return true;
}
catch (Exception e)
{
return false;
}
}
/// <summary>
/// 收数据。
/// </summary>
private void AcceptMsgs()
{
try
{
while (true)
{
byte[] buffer = new byte[MAX_SEND_FILE_LENGTH];
int dataLength = clientSocket.Receive(buffer);
if (dataLength == 0)
{
//长度为0表示没接受到内容。断开。
break;
}
string strMsg = Encoding.UTF8.GetString(buffer, 0, dataLength);
Debug.Log("客户端接受到消息:" + strMsg);
Loom.QueueOnMainThread((param) =>
{
delegateMsg(strMsg);
}, null);
}
}
catch (Exception e)
{
}
}
/// <summary>
/// 发送文本消息
/// </summary>
/// <param name="msg"></param>
public bool SubmitMsgToServer(string msg)
{
if (clientSocket == null || !clientSocket.Connected)
{
return false;
}
try
{
byte[] buffer = Encoding.UTF8.GetBytes(msg);
//发送给服务端
clientSocket.Send(buffer);
return true;
}
catch (Exception e)
{
Debug.Log("客户端发送数据发生异常:" + e.ToString());
return false;
}
}
public bool ClientClose()
{
if (clientSocket == null || !clientSocket.Connected)
{
return false;
}
try
{
clientSocket.Close();
return true;
}
catch (Exception e)
{
Debug.Log("关闭客户端发生异常:" + e.ToString());
return false;
}
}
}
3.创建脚本"Loom.cs" 实现将线程中的获取到的服务器消息传递到主线程中 "Loom.cs"脚本挂在再Unity场景中
using UnityEngine;
using System.Collections.Generic;
using System;
using System.Threading;
using System.Linq;
public class Loom : MonoBehaviour
{
//是否已经初始化
static bool isInitialized;
private static Loom _ins;
public static Loom ins { get { Initialize(); return _ins; } }
void Awake()
{
_ins = this;
isInitialized = true;
}
//初始化
public static void Initialize()
{
if (!isInitialized)
{
if (!Application.isPlaying)
return;
isInitialized = true;
var obj = new GameObject("Loom");
_ins = obj.AddComponent<Loom>();
DontDestroyOnLoad(obj);
}
}
//单个执行单元（无延迟）
struct NoDelayedQueueItem
{
public Action<object> action;
public object param;
}
//全部执行列表（无延迟）
List<NoDelayedQueueItem> listNoDelayActions = new List<NoDelayedQueueItem>();
//单个执行单元（有延迟）
struct DelayedQueueItem
{
public Action<object> action;
public object param;
public float time;
}
//全部执行列表（有延迟）
List<DelayedQueueItem> listDelayedActions = new List<DelayedQueueItem>();
//加入到主线程执行队列（无延迟）
public static void QueueOnMainThread(Action<object> taction, object param)
{
QueueOnMainThread(taction, param, 0f);
}
//加入到主线程执行队列（有延迟）
public static void QueueOnMainThread(Action<object> action, object param, float time)
{
if (time != 0)
{
lock (ins.listDelayedActions)
{
ins.listDelayedActions.Add(new DelayedQueueItem { time = Time.time + time, action = action, param = param });
}
}
else
{
lock (ins.listNoDelayActions)
{
ins.listNoDelayActions.Add(new NoDelayedQueueItem { action = action, param = param });
}
}
}
//当前执行的无延时函数链
List<NoDelayedQueueItem> currentActions = new List<NoDelayedQueueItem>();
//当前执行的有延时函数链
List<DelayedQueueItem> currentDelayed = new List<DelayedQueueItem>();
void Update()
{
if (listNoDelayActions.Count > 0)
{
lock (listNoDelayActions)
{
currentActions.Clear();
currentActions.AddRange(listNoDelayActions);
listNoDelayActions.Clear();
}
for (int i = 0; i < currentActions.Count; i++)
{
currentActions[i].action(currentActions[i].param);
}
}
if (listDelayedActions.Count > 0)
{
lock (listDelayedActions)
{
currentDelayed.Clear();
currentDelayed.AddRange(listDelayedActions.Where(d => Time.time >= d.time));
for (int i = 0; i < currentDelayed.Count; i++)
{
listDelayedActions.Remove(currentDelayed[i]);
}
}
for (int i = 0; i < currentDelayed.Count; i++)
{
currentDelayed[i].action(currentDelayed[i].param);
}
}
}
void OnDisable()
{
if (_ins == this)
{
_ins = null;
}
}
}
4.使用方法
SocketClient client = new SocketClient(ip, port);
isConnect = client.ConnectServer();
-服务器端
在VisualStudio2022中添加以下脚本"SocketServer.cs"
using System;
using System.Collections.Generic;
using System.Linq;
using System.Net.Sockets;
using System.Net;
using System.Text;
using System.Threading;
using System.Threading.Tasks;
public delegate void DelegateMsg(string Msg);
namespace WindowsFormsAppSocektServer
{
internal class SocketServer
{
//端口号
private int SocketServerPort = 10001;
//处理连接请求的线程
private Thread acceptConnectReqThd;
private Socket _clientSocket;
private int MAX_SEND_FILE_LENGTH = 4096;
public DelegateMsg delegateMsg;
/// <summary>
/// 启动服务器
/// </summary>
public bool Start(string _ip,int _port)
{
try
{
//创建一个socket对象
Socket socketWatch = new Socket(AddressFamily.InterNetwork, SocketType.Stream, ProtocolType.Tcp);
//获取IP
IPAddress ip = IPAddress.Parse(_ip);//IPAddress.Any;
//创建端口号
IPEndPoint port = new IPEndPoint(ip, _port/*SocketServerPort*/);
//监听
socketWatch.Bind(port);
Console.WriteLine("监听成功");
socketWatch.Listen(20); //设定最大的挂起长度
//新建线程来处理连接请求
acceptConnectReqThd = new Thread(AcceptConnectReqHandler);
acceptConnectReqThd.IsBackground = true;
acceptConnectReqThd.Start(socketWatch); //把socket对象当做参数传递给到线程里面的方法
return true;
}
catch (Exception e)
{
return false;
}
}
/// <summary>
/// 连接请求的处理函数
/// </summary>
/// <param name="_socket"></param>
private void AcceptConnectReqHandler(object _socket)
{
try
{
//服务端的socket对象
Socket serverSocket = (Socket)_socket;
while (true)
{
//获取客户端socket。Accept方法处理任何传入的连接请求，并返回可用于与远程主机通信数据的Socket对象，即客户端的socket。
//这一句话会卡主线程。只要没有新的链接进来，就会一直卡主不动（等待中）。
//收到连接事件后，会往下执行，通过while又回到这里继续等待
Socket clientSocket = serverSocket.Accept();
//创建接受客户端消息的线程
Thread acceptMsgReqThd = new Thread(ReciveMsgReqHandler);
acceptMsgReqThd.IsBackground = true;
acceptMsgReqThd.Start(clientSocket);
}
}
catch (Exception e)
{
Console.WriteLine("服务端处理连接事件异常:" + e.ToString());
}
}
/// <summary>
/// 接收客户端socket消息
/// </summary>
/// <param name="_socket"></param>
private void ReciveMsgReqHandler(object _socket)
{
Socket clientSocket = (Socket)_socket;
_clientSocket = clientSocket;
try
{
while (true)
{
//客户端连接成功后，接受来自客户端的消息
if (clientSocket == null)
{
continue;
}
byte[] buffer = new byte[MAX_SEND_FILE_LENGTH]; //数据缓冲区。
//实际接收到的有效字节数
//Receive也是个卡线程的方法
Console.WriteLine("等待接受客户端的数据:");
int dataLength = clientSocket.Receive(buffer);
Console.WriteLine("接受到客户端的数据，字节数:" + dataLength);
//如果客户端关闭，发送的数据就为空，就跳出循环
if (dataLength == 0)
{
break;
}
//假设收到的是个字符串（先这么假定），转成字符串处理
//string strMsg = Encoding.UTF8.GetString(buffer, 1, dataLength - 1);
string strMsg = Encoding.UTF8.GetString(buffer,0, dataLength);
Console.WriteLine("接受到客户端的消息:" + strMsg);
delegateMsg(strMsg);
}
//中止当前线程
//Thread.CurrentThread.Abort();
}
catch (Exception e)
{
SocketException socketExp = e as SocketException;
if (socketExp != null && socketExp.NativeErrorCode == 10054)
{
Console.WriteLine("socket客户端关闭:" + e.ToString());
}
else
{
Console.WriteLine("======接受消息异常：" + e.ToString());
}
//中止当前线程
//Thread.CurrentThread.Abort();
}
}
public void SendToClient(string sendMsg)
{
if (_clientSocket != null)
{
byte[] buffer = Encoding.UTF8.GetBytes(sendMsg);
//发送给客户端
_clientSocket.Send(buffer);
}
}
}
}
- 使用方法
socketServer = new SocketServer();
socketServer.Start(IP,Port);
下载地址： 链接：https://pan.baidu.com/s/167XeUUsulXHHtIdeIfhgeA?pwd=btvd 提取码：btvd
